Description

Description
Drone type: Tailsitter vertical take-off and landing (VTOL)
Max. take-off weight: 4.5 kg (9.9 lb)
Weight (empty): 3.7 kg (8.1 lb)
Max. payload weight: 800 g (1.8 lb)
Wingspan: 125 cm (4.1 ft)
Dimensions of WingtraOne: 125 × 68 × 12 cm (4.1 × 2.2 × 0.4 ft) (without middlestand)
Dimensions of pilot box: 57 × 37 × 20 cm, 8.6 kg (1.8 × 1.2 × 1.0 ft, 19 lb)
Battery capacity: Two 99 Wh batteries (a pair of batteries required)
Battery type: Li-ion, smart battery technology, UN3481 compliant
Radio link: Bi-directional 10 km (6 mi) in direct line of sight, keep in mind that obstacles reduce the range
Onboard GPS: Redundant, using GPS (L1, L2), GLONASS (L1, L2), Galileo (L1) and BeiDou (L1)
Frequencies range: 1227.6 MHz / 1242.9375-1251.6875 MHz / 1561,098 MHz / 1575,42 MHz / 1598.0625-1609.3125 MHz / 1602,00 MHz
Dimensions of travel hardcase (optional): 137 x 67 x 23 cm (54 x 26 x 9 in)
Weight of travel hardcase including the drone: 18.6 kg (41 lb)

Operations
Flight speed: 16 m/s (35.8 mph)
Wind resistance:
Max sustained wind: 12 m/s (27 mph)
Max wind gusts: 18 m/s (40 mph)
Max sustained wind on the ground: 8/ms (19 mph)
Maximum flight time: Up to 59 min
See Knowledge Base for what flight time to expect in different flying conditions
Min. space for take-off and landing: 2 m × 2 m (6.6 ft × 6.6 ft)
Temperature: -10 to +40 °C (14 to 104 °F)
Max. take-off altitude above sea level: 2500 m (8200 ft)
With high-altitude propellers it is possible to take off from up to 4800 m (15,700 ft) and fly up to 5000 m (16,400 ft) AMSL
Weather: IP54, not recommended to fly in fog, rain and snow
Ground Control Points required:
No (with PPK option)
Using 3 checkpoints to verify the accuracy is recommended
Auto-Landing accuracy: < 2 m (< 7 ft)
